Indoor Rental LED Display· P2.6 Indoor Rental LED Display fo […]
Product details
Indoor Rental LED Display·
P2.6 Indoor Rental LED Display for Events & Church
Lightweight, quick-install indoor LED rental screen designed for events, stages, churches, conferences, trade shows, and live production environments.
Product Overview
YOUXIAN Indoor Rental LED Display is designed for professional event rental and fixed temporary installations. With a lightweight die-cast aluminum cabinet, fast-lock structure, front and rear service access, and multiple installation options, it helps event companies and AV integrators build high-impact video walls quickly and efficiently.
Available in multiple pixel pitches from P1.5625 to P3.91, the series supports close-view indoor applications as well as larger stage and event screens. It is ideal for customers who need a bright, smooth, easy-to-install LED wall with reliable visual performance.
Core Advantages
| Feature | Customer Benefit |
| Quick Installation | Fast locks and positioning design help crews assemble and dismantle the LED wall quickly, reducing labor time for rental projects. |
| Lightweight Die-Cast Cabinet | 500 x 500mm cabinet weighs approx. 8kg; 500 x 1000mm cabinet weighs approx. 14.5kg, helping reduce transport and installation cost. |
| Front & Rear Maintenance | Modules and power boxes can be serviced from the front or rear, making the screen easier to maintain in different venues. |
| Seamless Splicing | CNC-processed die-cast aluminum cabinet supports cabinet flatness up to <=0.1mm for a cleaner video wall surface. |
| High Refresh Rate | 3840Hz refresh rate helps deliver smooth video playback and better camera performance for events and live production. |
| High Contrast & Color Enhancement | Special mask texture and color enhancement help improve contrast, black level and image depth for indoor viewing. |
| Wide Viewing Angle | 160° horizontal and vertical viewing angle helps audiences see clear images from different positions in the venue. |
| Flexible Installation | Supports hanging, stacking, and arc-shape installation for stages, creative backdrops and event layouts. |
Available Models & Recommended Use
| Pixel Pitch | Best For | Brightness | Recommended Viewing Distance |
| P1.5625 | Premium close-view indoor events, conference rooms, control rooms, broadcast backgrounds | >=600 nits | 2-50m |
| P1.95 | High-definition indoor events, churches, showrooms, corporate presentation walls | >=800 nits | 2-50m |
| P2.604 | Popular rental option for medium-size event screens and stage backdrops | >=800 nits | 3-50m |
| P2.976 | Cost-effective event screen for concerts, churches, exhibitions and medium viewing distance | >=800 nits | 3-100m |
| P3.91 | Large indoor rental screens, concerts, stage backdrops and long-view event spaces | >=1000 nits | 4-100m |
How to Choose the Right Pixel Pitch
| Model Range | Selection Guide |
| P1.5625 / P1.95 | Choose these models when the audience is close to the screen and high image detail is required. |
| P2.604 | A balanced option when image quality, cost and rental flexibility all matter. |
| P2.976 | Recommended for standard indoor rental projects that need good image quality with better cost control. |
| P3.91 | Suitable for larger stages, concerts and event screens where the audience watches from a farther distance. |
Not sure which pixel pitch is right for your project? Tell us your screen size, installation method, viewing distance and event type. We will recommend the most cost-effective model for your project.
Quick Specifications
| Item | Specification |
| Cabinet Size | 500 x 500 x 84.5mm; 500 x 1000 x 84.5mm available for selected configurations |
| Cabinet Weight | Approx. 8kg for 500 x 500mm; approx. 14.5kg for 500 x 1000mm |
| Cabinet Material | Die-casting aluminum |
| Maintenance | Front and rear service access |
| Refresh Rate | 3840Hz |
| Gray Scale | 16bit |
| Contrast Ratio | 10000:1 |
| Viewing Angle | 160° horizontal / 160° vertical |
| Protection Level | IP31 for indoor use |
| Power Input | AC90-264V, 47-63Hz |
| Working Environment | -20°C to 60°C, 10%-85% RH |
Detailed Model Parameters
| Model | Pixel Density | Module Res. | Cabinet Res. | Cabinet Size | Weight |
| P1.5625(GOB) | 409,600 dots/sqm | 160 x 160 | 320 x 320/ 320 x 640 | 500 x 500 / 500 x 1000 x 84.5mm | 8kg / 14.5kg |
| P1.95(GOB) | 262,144 dots/sqm | 128 x 128 | 256 x 256/ 256 x 512 | 500 x 500 / 500 x 1000 x 84.5mm | 8kg / 14.5kg |
| P2.604 | 147,456 dots/sqm | 96 x 96 | 192 x 192/ 192 x 384 | 500 x 500 / 500 x 1000 x 84.5mm | 8kg / 14.5kg |
| P2.976 | 112,896 dots/sqm | 84 x 84 | 168 x 168 / 168 x 336 | 500 x 500 / 500 x 1000 x 84.5mm | 8kg / 14.5kg |
| P3.91 | 65,536 dots/sqm | 64 x 64 | 128 x 128 / 128 x 256 | 500 x 500 / 500 x 1000 x 84.5mm | 8kg / 14.5kg |
Shared Optical & Electrical Parameters
| Parameter | Value / Description |
| Color Temperature | 1000-18500K adjustable |
| Frame Frequency | 50/60Hz |
| Max. Power Consumption | 600W/sqm |
| Average Power Consumption | 200-300W/sqm |
| Module Size | 250 x 250mm |
| Module Quantity | 2 x 2 for 500 x 500mm; 2 x 4 for 500 x 1000mm |
| Service Design | HUB connection with integrated power box; plug-and-play and hot-swapping support |
| Mechanical Design | Multi-handles, corner protection, fast locks, positioning grooves and power/signal indicators |
Application Scenarios
| Application | Typical Use |
| Concerts & Live Shows | Stage background screens, side screens, DJ booth visuals, touring events |
| Churches & Worship Venues | Indoor worship screens, sermon visuals, stage backdrop, live streaming support |
| Corporate Events | Product launches, annual meetings, conference halls, brand presentations |
| Trade Shows & Exhibitions | Booth video walls, product demos, high-impact advertising displays |
| Hotels & Ballrooms | Banquets, weddings, commercial events, indoor entertainment venues |
| Schools & Auditoriums | Ceremonies, performances, lecture halls, indoor public events |
The Series Indoor Rental LED Display is a professional LED video wall solution for events, stages, churches, conferences and live productions. It is lightweight, easy to install and flexible enough for hanging, stacking and curved screen setups. With high refresh rate, wide viewing angle and high contrast performance, it delivers smooth and vivid visuals for both live audiences and camera recording.
For event rental companies, AV integrators and venue operators, this series helps reduce setup time, simplify maintenance and create impressive indoor visual experiences with reliable performance.
Tell us your stage size, viewing distance and installation method. We will recommend the right pixel pitch and provide a complete LED wall solution for your event project.
